QSC TouchMix 16 20-channel Compact Digital Mixer

QSC TouchMix 16 20-channel Compact Digital Mixer

$1,699.00
$1,699.00
Sale Sold out

+ Free Shipping

Blink Image Blink Image

Ready to ship immediately!

The QSC TouchMix-16 is a revolutionary mixer perfect for musicians, production specialists and even live performances that offers all the capabilities of a large mixing console in a compact and easy to use package. The TouchMix line offers an amazing range of functionality, enough to satisfy even the most demanding professionals, but also an assortment of features that allow less experienced users to achieve superior results. Get yours today at Alto Music!
View full details
  • Details
  • Features
  • Tech Specs
  • Reviews

The QSC TouchMix-16 is a revolutionary mixer perfect for musicians, production specialists and even liver performance that offers all the capabilities of a large mixing console in a compact and easy to use package. TouchMix have an amazing range of functionality, enough to satisfy even the most demanding professionals, but also an assortment of features that allow less experienced users to achieve superior results.

  • 8x Mic Inputs, 4x Mic/Line Combo Inputs, 2x Stereo Line Inputs, Built-in FX, & iPad Remote Control via Wi-Fi
  • With multiple modes, accessible to both novices and professionals, the TouchMix 16 gives you professional results made easy
  • Simple mode offers exactly what it says- simplicity. Similar to the “Auto” function on a camera, this mode will have you mixing like a pro with minimal effort and expertise
  • Want a bit more control? The advanced mode on TouchMix 16 gives you total control over all mixing functions to fine tune every nuance the way you please
  • Built in color touch screen makes the TouchMix stand out from the competition
  • Compact and portable, the TouchMix is roughly the size of a small laptop computer- who needs more weighty gear to lug around in their setup?
  • TouchMix 16 gives you all the power and features of a professional mixer at a fraction of the cost and is sure to please even the pickiest sound engineer
  • Multitrack direct to disk recording/playback via external USB hard drive (not included.) No computer required
  • Multiple monitor mixes including ability to drive in-ears directly
  • 1/3 octave graphic EQ, notch filters, limiters and delay on main and aux. outputs, DCA’s and mute groups High Quality microphone preamps Channel-selectable phantom power
  • USB WI-Fi adapter included, control remotely with your mobile device!
  • Includes padded carrying case
More Information
Product Name QSC TouchMix 16 20-channel Compact Digital Mixer
Brand QSC
Condition New
MPN TOUCHMIX16
UPC 684284061546
Shipping Option Free Shipping to the Continental U.S.
  • 20 total inputs: 16 mic, (four with XLR/TRS combo connector) and two stereo line (TRS)
  • Dedicated talkback mic input
  • Stereo Main L/R outputs (XLR)
  • Ample monitor outputs (eight total) with 6 mono auxiliary mixes (XLR) and 2 stereo auxiliary mixes.
    • The 2 stereo aux outputs can drive wired in-ear monitors (IEM) directly.
    • Mono auxiliaries may be linked for stereo use.
  • Superb sound quality
    • Class-A microphone pre-amps
    • 32-bit floating point processing
    • 24-bit AD & DA convertors
  • Input channels are fully-featured:
    • Four-band full parametric EQ
    • Variable high-cut and low-cut filters
    • Gate
    • Compressor (with de-esser)
  • Main and auxiliary outputs feature:
    • 1/3-octave graphic EQ (four-band parametric EQ on stereo auxiliaries)
    • Limiter
    • Delay
    • Notch filters
  • Four professional quality stereo DSP effects. Choose from:
    • Two types of reverb
    • Mono delay
    • Stereo delay
    • Chorus
    • Pitch-change
  • A pitch correct processor is assignable to any input channel.
  • Eight DCA and eight mute groups.
  • Color, capacitive touch screen graphical user interface combined with hardware controls for fast and intuitive operation.
  • Great results and easy to use
    • Input channel preset library features over 100 presets developed by experienced concert engineers specifically for live sound applications.
    • Wizards assist with input gain adjustment and effects selection and routing.
    • On board Info system gives you instant access to the user manual.
  • Save your own channel presets and complete mixer scenes to internal memory or USB device.
  • Capturing live performance to multi-track has never been easier. Record 22 tracks (all inputs plus a stereo mix) directly to USB hard-drive. Mix down on TouchMix or import into your favorite DAW.
  • Complete mixer remote control via free iPad® App.
  • Monitor control via iPhone/iPod Touch App.
  • Multiple Wi-Fi Connectivity options
  • Security Lockout Modes
  • USB Wi-Fi interface and carrying case are included.
Display 6.1 x 3.5" (156 x 90 mm) color TFT, touch sensing
Input 20x Total
4x Combo XLR/TRS
12x XLR
2x Stereo 1/4" (6.3 mm) TRS
1x XLR talkback
Output 2x Main XLR, line level
6x Aux XLR, line level
2x Stereo Aux TRS (line or ear monitors, 16 O minimum impedance)
1x Stereo monitor TRS (line or headphone, 16 O minimum impedance)
1x Stereo cue TRS (line or headphone, 16 O minimum impedance)
Processing Mic & Line Input Processing:
4-band parametric EQ with Hi/Low shelving option
Variable 24 dB/octave HPF & LPF
Gate
Compressor

2-Track (USB) & FX Return Processing:
2-band shelving EQ
Variable 24 db/octave HPF
Gate
Compressor

Output Channel Processing:
Main Output & Auxes 1 to 6: 1/3 octave graphic EQ, variable HPF & LPF, 4-band variable notch filter, limiter
Auxes 7/8, 9/10: 4-band parametric EQ, limiter
Recording 20 tracks, requires USB 3.0 Hard Drive, minimum 7800 RPM
Groups 8 DCA groups (with mutes)
8 Mute groups
Cue Input priority cue
AFL
PFL
Solo in place
Effects Reverb, echo, delay, chorus
1x Pitch Correct (assignable to any mono input channel)
50x factory presets
50x user presets
Preset Mixer Presets:
Factory & user mixer presets including all mixer parameters may be stored internally or loaded to / from USB

Channel Preset:
User channel presets may be stored internally or loaded to / from USB
Control iOS mixer app for iPad, control via Wi-Fi provides access to all mixer functions
Wi-Fi USB Wi-Fi adapter included
Line Voltage 100 V AC - 240 V AC, 50 - 60 Hz
Sampling Frequency 44.1/48 kHz
Internal Processing 32-bit floating point
Frequency Response 20 Hz to 20 kHz, +/-0.5 dB, any input to any output
Dynamic Range 105 dB
EIN -128 dBu
Output Noise Residual Output Noise: -86 dBu
Crosstalk -80 dB
Signal to Noise Ratio -94 dB
Maximum Input Level +16 dB (Mic inputs)
+22 dB (Line inputs)
Phantom Power 48 V, individually switchable per channel
Dimensions 3.5 x 14.2 x 11.7" (89 x 360 x 297 mm)
Weight 5.9 lb (2.98 kg)

QSC TouchMix 16 20-channel Compact Digital Mixer
Details

The QSC TouchMix-16 is a revolutionary mixer perfect for musicians, production specialists and even liver performance that offers all the capabilities of a large mixing console in a compact and easy to use package. TouchMix have an amazing range of functionality, enough to satisfy even the most demanding professionals, but also an assortment of features that allow less experienced users to achieve superior results.

  • 8x Mic Inputs, 4x Mic/Line Combo Inputs, 2x Stereo Line Inputs, Built-in FX, & iPad Remote Control via Wi-Fi
  • With multiple modes, accessible to both novices and professionals, the TouchMix 16 gives you professional results made easy
  • Simple mode offers exactly what it says- simplicity. Similar to the “Auto” function on a camera, this mode will have you mixing like a pro with minimal effort and expertise
  • Want a bit more control? The advanced mode on TouchMix 16 gives you total control over all mixing functions to fine tune every nuance the way you please
  • Built in color touch screen makes the TouchMix stand out from the competition
  • Compact and portable, the TouchMix is roughly the size of a small laptop computer- who needs more weighty gear to lug around in their setup?
  • TouchMix 16 gives you all the power and features of a professional mixer at a fraction of the cost and is sure to please even the pickiest sound engineer
  • Multitrack direct to disk recording/playback via external USB hard drive (not included.) No computer required
  • Multiple monitor mixes including ability to drive in-ears directly
  • 1/3 octave graphic EQ, notch filters, limiters and delay on main and aux. outputs, DCA’s and mute groups High Quality microphone preamps Channel-selectable phantom power
  • USB WI-Fi adapter included, control remotely with your mobile device!
  • Includes padded carrying case
More Information
Product Name QSC TouchMix 16 20-channel Compact Digital Mixer
Brand QSC
Condition New
MPN TOUCHMIX16
UPC 684284061546
Shipping Option Free Shipping to the Continental U.S.
Features
  • 20 total inputs: 16 mic, (four with XLR/TRS combo connector) and two stereo line (TRS)
  • Dedicated talkback mic input
  • Stereo Main L/R outputs (XLR)
  • Ample monitor outputs (eight total) with 6 mono auxiliary mixes (XLR) and 2 stereo auxiliary mixes.
    • The 2 stereo aux outputs can drive wired in-ear monitors (IEM) directly.
    • Mono auxiliaries may be linked for stereo use.
  • Superb sound quality
    • Class-A microphone pre-amps
    • 32-bit floating point processing
    • 24-bit AD & DA convertors
  • Input channels are fully-featured:
    • Four-band full parametric EQ
    • Variable high-cut and low-cut filters
    • Gate
    • Compressor (with de-esser)
  • Main and auxiliary outputs feature:
    • 1/3-octave graphic EQ (four-band parametric EQ on stereo auxiliaries)
    • Limiter
    • Delay
    • Notch filters
  • Four professional quality stereo DSP effects. Choose from:
    • Two types of reverb
    • Mono delay
    • Stereo delay
    • Chorus
    • Pitch-change
  • A pitch correct processor is assignable to any input channel.
  • Eight DCA and eight mute groups.
  • Color, capacitive touch screen graphical user interface combined with hardware controls for fast and intuitive operation.
  • Great results and easy to use
    • Input channel preset library features over 100 presets developed by experienced concert engineers specifically for live sound applications.
    • Wizards assist with input gain adjustment and effects selection and routing.
    • On board Info system gives you instant access to the user manual.
  • Save your own channel presets and complete mixer scenes to internal memory or USB device.
  • Capturing live performance to multi-track has never been easier. Record 22 tracks (all inputs plus a stereo mix) directly to USB hard-drive. Mix down on TouchMix or import into your favorite DAW.
  • Complete mixer remote control via free iPad® App.
  • Monitor control via iPhone/iPod Touch App.
  • Multiple Wi-Fi Connectivity options
  • Security Lockout Modes
  • USB Wi-Fi interface and carrying case are included.
Tech Specs
Display 6.1 x 3.5" (156 x 90 mm) color TFT, touch sensing
Input 20x Total
4x Combo XLR/TRS
12x XLR
2x Stereo 1/4" (6.3 mm) TRS
1x XLR talkback
Output 2x Main XLR, line level
6x Aux XLR, line level
2x Stereo Aux TRS (line or ear monitors, 16 O minimum impedance)
1x Stereo monitor TRS (line or headphone, 16 O minimum impedance)
1x Stereo cue TRS (line or headphone, 16 O minimum impedance)
Processing Mic & Line Input Processing:
4-band parametric EQ with Hi/Low shelving option
Variable 24 dB/octave HPF & LPF
Gate
Compressor

2-Track (USB) & FX Return Processing:
2-band shelving EQ
Variable 24 db/octave HPF
Gate
Compressor

Output Channel Processing:
Main Output & Auxes 1 to 6: 1/3 octave graphic EQ, variable HPF & LPF, 4-band variable notch filter, limiter
Auxes 7/8, 9/10: 4-band parametric EQ, limiter
Recording 20 tracks, requires USB 3.0 Hard Drive, minimum 7800 RPM
Groups 8 DCA groups (with mutes)
8 Mute groups
Cue Input priority cue
AFL
PFL
Solo in place
Effects Reverb, echo, delay, chorus
1x Pitch Correct (assignable to any mono input channel)
50x factory presets
50x user presets
Preset Mixer Presets:
Factory & user mixer presets including all mixer parameters may be stored internally or loaded to / from USB

Channel Preset:
User channel presets may be stored internally or loaded to / from USB
Control iOS mixer app for iPad, control via Wi-Fi provides access to all mixer functions
Wi-Fi USB Wi-Fi adapter included
Line Voltage 100 V AC - 240 V AC, 50 - 60 Hz
Sampling Frequency 44.1/48 kHz
Internal Processing 32-bit floating point
Frequency Response 20 Hz to 20 kHz, +/-0.5 dB, any input to any output
Dynamic Range 105 dB
EIN -128 dBu
Output Noise Residual Output Noise: -86 dBu
Crosstalk -80 dB
Signal to Noise Ratio -94 dB
Maximum Input Level +16 dB (Mic inputs)
+22 dB (Line inputs)
Phantom Power 48 V, individually switchable per channel
Dimensions 3.5 x 14.2 x 11.7" (89 x 360 x 297 mm)
Weight 5.9 lb (2.98 kg)
