*Please note -- This pre-owned item may show signs of use. Please refer to the photos for details of the product.
Live or in the studio, Allen & Heath's ZED60-10FX is an ultra-portable mixer for solo artists and small bands. The ZED60-10FX adds premium quality 60mm faders for that intuitive, tactile mixing experience. This small, 6-channel mixer packs an incredible amount of connectivity along with built-in digital effects. It's a great companion for live mixing, live recording, and multi tracking over USB. It features 4 mic/line inputs with 3-band EQ and Phantom Power. Channels 3 and 4 have 1/4-inch Hi-Z instrument-level inputs for connecting guitars, electric basses, etc.
| Product Name | Allen and Heath ZED60-10FX 10-channel Mixer |
|---|---|
| Brand | Allen |
| Condition | Pre-Owned |
| MPN | AH-ZED60-10FX |
| UPC | 6938122238701 |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- Allen and Heath ZED60-10FX 10-channel Mixer
- High-performance multipurpose mixer with FX and USB I/O port for live sound and recording
- Features premium quality 60mm faders for intuitive, tactile mixing
- Includes 4 Mic/Line and 2 Stereo Inputs for versatile audio input options
- Configurable USB audio in/out for easy stereo recording at gigs or in the studio
- Equipped with professional XLR main stereo outputs and 16 stunning FX
- Responsive 3-band British EQ with sweepable mid frequency for precise audio adjustment
Inputs |
|
|---|---|
| Input Mono Channel (XLR) | -10 to -60 dBu nominal (+11 dBu maximum) |
| Input Mono Channel Line Input | +10 to -40 dBu (+31 dBu maximum) |
| Input Stereo Input | 0 dBu nominal (control = Off to +15 dB) |
Outputs |
|
| L/R Outputs (XLR) Normal / DI Out | 0 dBu / -30 dBu nominal, +21 dBu / -9 dBu maximum |
| Aux & FX Outputs (Jack) | 0 dBu nominal, +21 dBu maximum |
| Record & Monitor Outputs | 0 dBu nominal, +21 dBu maximum |
Frequency Response |
|
| Mic In to Mix L/R Out (30 dB Gain) | +0.5 / -1 dB, 10 Hz to 30 kHz |
| Line In to Mix L/R Out (0 dB Gain) | +0.5 / -1 dB, 10 Hz to 25 kHz |
| Stereo In to Mix L/R Out | +0.5 / -1 dB, 10 Hz to 30 kHz |
THD+N |
|
| Mic In to Mix L/R Out (10 dB Gain, 1 kHz, +10 dBu Out) | 0.002% |
| Mic In to Mix L/R Out (30 dB Gain, 1 kHz) | 0.01% |
| Line In to Mix L/R Out (0 dB Gain, 0 dBu, 1 kHz) | 0.003% |
| Stereo In to Mix L/R Out (0 dB Gain, +10 dBu, 1 kHz) | 0.002% |
| Guitar Input to Mix L/R Out (0 dBu, Boost Out) | 0.015% |
| Guitar Input to Mix L/R Out (0 dBu, Boost In) | 2% Second Harmonic |
Headroom |
|
| Analogue Headroom from Nominal (0 VU) | 21 dB |
| USB In & Out Headroom from Nominal (0 VU) | 14 dB |
USB Audio |
|
| USB Audio In/Out | USB 1.1 compliant, 16-bit |
Sample Rate |
|
| Supported Sample Rates | 32 kHz, 44.1 kHz, 48 kHz |
Noise |
|
| Mic Pre EIN (Max Gain, 150Ω, 22–22 kHz) | -127 dBu |
| Mix L/R Out (Faders 0, Levels Min, 22–22 kHz) | -96 dBu |
Physical |
|
| Dimensions (W x D x H) | 13.22 x 13.62 x 3.74" / 336 x 346 x 95 mm |
Allen and Heath ZED60-10FX 10-channel Mixer
*Please note -- This pre-owned item may show signs of use. Please refer to the photos for details of the product.
Live or in the studio, Allen & Heath's ZED60-10FX is an ultra-portable mixer for solo artists and small bands. The ZED60-10FX adds premium quality 60mm faders for that intuitive, tactile mixing experience. This small, 6-channel mixer packs an incredible amount of connectivity along with built-in digital effects. It's a great companion for live mixing, live recording, and multi tracking over USB. It features 4 mic/line inputs with 3-band EQ and Phantom Power. Channels 3 and 4 have 1/4-inch Hi-Z instrument-level inputs for connecting guitars, electric basses, etc.
| Product Name | Allen and Heath ZED60-10FX 10-channel Mixer |
|---|---|
| Condition | Pre-Owned |
| MPN | AH-ZED60-10FX |
| UPC | 6938122238701 |
What's in the Box?
Allen and Heath ZED60-10FX 10-channel Mixer- High-performance multipurpose mixer with FX and USB I/O port for live sound and recording
- Features premium quality 60mm faders for intuitive, tactile mixing
- Includes 4 Mic/Line and 2 Stereo Inputs for versatile audio input options
- Configurable USB audio in/out for easy stereo recording at gigs or in the studio
- Equipped with professional XLR main stereo outputs and 16 stunning FX
- Responsive 3-band British EQ with sweepable mid frequency for precise audio adjustment
Inputs |
|
|---|---|
| Input Mono Channel (XLR) | -10 to -60 dBu nominal (+11 dBu maximum) |
| Input Mono Channel Line Input | +10 to -40 dBu (+31 dBu maximum) |
| Input Stereo Input | 0 dBu nominal (control = Off to +15 dB) |
Outputs |
|
| L/R Outputs (XLR) Normal / DI Out | 0 dBu / -30 dBu nominal, +21 dBu / -9 dBu maximum |
| Aux & FX Outputs (Jack) | 0 dBu nominal, +21 dBu maximum |
| Record & Monitor Outputs | 0 dBu nominal, +21 dBu maximum |
Frequency Response |
|
| Mic In to Mix L/R Out (30 dB Gain) | +0.5 / -1 dB, 10 Hz to 30 kHz |
| Line In to Mix L/R Out (0 dB Gain) | +0.5 / -1 dB, 10 Hz to 25 kHz |
| Stereo In to Mix L/R Out | +0.5 / -1 dB, 10 Hz to 30 kHz |
THD+N |
|
| Mic In to Mix L/R Out (10 dB Gain, 1 kHz, +10 dBu Out) | 0.002% |
| Mic In to Mix L/R Out (30 dB Gain, 1 kHz) | 0.01% |
| Line In to Mix L/R Out (0 dB Gain, 0 dBu, 1 kHz) | 0.003% |
| Stereo In to Mix L/R Out (0 dB Gain, +10 dBu, 1 kHz) | 0.002% |
| Guitar Input to Mix L/R Out (0 dBu, Boost Out) | 0.015% |
| Guitar Input to Mix L/R Out (0 dBu, Boost In) | 2% Second Harmonic |
Headroom |
|
| Analogue Headroom from Nominal (0 VU) | 21 dB |
| USB In & Out Headroom from Nominal (0 VU) | 14 dB |
USB Audio |
|
| USB Audio In/Out | USB 1.1 compliant, 16-bit |
Sample Rate |
|
| Supported Sample Rates | 32 kHz, 44.1 kHz, 48 kHz |
Noise |
|
| Mic Pre EIN (Max Gain, 150Ω, 22–22 kHz) | -127 dBu |
| Mix L/R Out (Faders 0, Levels Min, 22–22 kHz) | -96 dBu |
Physical |
|
| Dimensions (W x D x H) | 13.22 x 13.62 x 3.74" / 336 x 346 x 95 mm |
