ATC P1 Pro Dual-Mono Power Amplifier
- True dual-mono design delivers full power simultaneously from both channels, with minimal crosstalk
- Grounded source class A/B circuit topology as found in ATC’s renowned active loudspeakers.
- Ultra wide bandwidth, low distortion and high dynamic range ensure tonal accuracy and perfectly timed transients.
- No compromise, high performance power supply and large heatsinks guarantee outstanding stability and long term reliability.
- A perfect match for any passive studio reference monitor.
- 19” Rack mountable convection cooled chassis
| Product Name | ATC P1 Pro Dual-Mono Power Amplifier |
|---|---|
| Brand | ATC Loudspeakers |
| Condition | New |
| MPN | P1pro |
| Shipping Option | Free Shipping to the Continental U.S. |
- Output Power into 8 Ω: 150W (8 Ω, 1kHz, continuous. avg., both channels driven)
- Input Sensitivity: 2V RMS (ref. 150W out)
- Input Impedance:10kΩ/leg
- Frequency Response: <2Hz – >400kHz (-3dB)
- Signal to noise ratio: >115dB (IEC ‘A’)
- Crosstalk: >100dB (10Hz – 20kHz)
- THD: >0.002%/-95dB (8 Ω, 1kHz, -1dB below full Power)
- Damping Factor:>400 (8 Ω)
- Dimensions (HxWxD): 141.1×482.6×365.6mm (3U tall with feet removed)
- Weight: 20kg/44lbs
ATC P1 Pro Dual-Mono Power Amplifier
Details
ATC P1 Pro Dual-Mono Power Amplifier
- True dual-mono design delivers full power simultaneously from both channels, with minimal crosstalk
- Grounded source class A/B circuit topology as found in ATC’s renowned active loudspeakers.
- Ultra wide bandwidth, low distortion and high dynamic range ensure tonal accuracy and perfectly timed transients.
- No compromise, high performance power supply and large heatsinks guarantee outstanding stability and long term reliability.
- A perfect match for any passive studio reference monitor.
- 19” Rack mountable convection cooled chassis
| Product Name | ATC P1 Pro Dual-Mono Power Amplifier |
|---|---|
| Brand | ATC Loudspeakers |
| Condition | New |
| MPN | P1pro |
| Shipping Option | Free Shipping to the Continental U.S. |
Tech Specs
- Output Power into 8 Ω: 150W (8 Ω, 1kHz, continuous. avg., both channels driven)
- Input Sensitivity: 2V RMS (ref. 150W out)
- Input Impedance:10kΩ/leg
- Frequency Response: <2Hz – >400kHz (-3dB)
- Signal to noise ratio: >115dB (IEC ‘A’)
- Crosstalk: >100dB (10Hz – 20kHz)
- THD: >0.002%/-95dB (8 Ω, 1kHz, -1dB below full Power)
- Damping Factor:>400 (8 Ω)
- Dimensions (HxWxD): 141.1×482.6×365.6mm (3U tall with feet removed)
- Weight: 20kg/44lbs
