Carl Martin Plexiranger Overdrive Pedal

Carl Martin Plexiranger Overdrive Pedal

Limited quantities available!

View full details
  • Details
  • Tech Specs
  • Reviews

When we look back to the glory days of rock guitar (mid 60's to mid 70's), some of the most popular amplifier set-ups were British Marshalls and Vox's.....often with multi-speaker cabinets. Players like Tony Iommi, Ritchie Blackmore, Brian May etc, carved their signature sounds on stage and in the studio with these rigs, and in order to deal with the over-powering bottom end, they made use of 'The Treble Booster'. Treble Boosters add top end or higher frequencies to the guitar tone, and depending on how the amp is set up, some much desired overdrive. As much as companies like Dallas (Rangemaster) and Hornby Skewes (Treble Booster) were solving a bottom-end problem, they had also created a new sound pallette! Carl decided it was time to re-introduce this sound with the PlexiRanger! And leave it to Carl to add a gain channel along with the boost channel for a one-of -a-kind fx pedal!

More Information
Product Name Carl Martin Plexiranger Overdrive Pedal
Shipping Option Free Shipping to the Continental U.S.
  • Input: 1M Ohm
  • Output: 200 Ohm
  • S/N Ratio: 54 dB
  • Tone: High Cut
  • Boost: +15dB
  • Range: +15dB
  • Freq: 250Hz-5kHz
  • Dimensions
    • 120 (W) x 95 (D) x 56 (H) mm
    • 4.72" (W) x 3.74" (D) x 2.2" (H)
  • Weight: 420g / 0,95lbs

Power Requirements

  • Battery: The PlexiRanger does not run on battery
  • Power consumption: max. 100mA.
  • Power supply: 9 V DC (regulated), 150 mA minimum, 2.1 mm female plug, center negative (-)
  • Please Use DC Power Supply Only! Failure to do so may damage the unit.

Carl Martin Plexiranger Overdrive Pedal

Details

When we look back to the glory days of rock guitar (mid 60's to mid 70's), some of the most popular amplifier set-ups were British Marshalls and Vox's.....often with multi-speaker cabinets. Players like Tony Iommi, Ritchie Blackmore, Brian May etc, carved their signature sounds on stage and in the studio with these rigs, and in order to deal with the over-powering bottom end, they made use of 'The Treble Booster'. Treble Boosters add top end or higher frequencies to the guitar tone, and depending on how the amp is set up, some much desired overdrive. As much as companies like Dallas (Rangemaster) and Hornby Skewes (Treble Booster) were solving a bottom-end problem, they had also created a new sound pallette! Carl decided it was time to re-introduce this sound with the PlexiRanger! And leave it to Carl to add a gain channel along with the boost channel for a one-of -a-kind fx pedal!

More Information
Product Name Carl Martin Plexiranger Overdrive Pedal
Shipping Option Free Shipping to the Continental U.S.
Tech Specs
  • Input: 1M Ohm
  • Output: 200 Ohm
  • S/N Ratio: 54 dB
  • Tone: High Cut
  • Boost: +15dB
  • Range: +15dB
  • Freq: 250Hz-5kHz
  • Dimensions
    • 120 (W) x 95 (D) x 56 (H) mm
    • 4.72" (W) x 3.74" (D) x 2.2" (H)
  • Weight: 420g / 0,95lbs

Power Requirements

  • Battery: The PlexiRanger does not run on battery
  • Power consumption: max. 100mA.
  • Power supply: 9 V DC (regulated), 150 mA minimum, 2.1 mm female plug, center negative (-)
  • Please Use DC Power Supply Only! Failure to do so may damage the unit.
