Loaded with premium features, this Pro-Mod Plus Dinky® DK24 2PT HSS E QM model features a sleek Dinky® body constructed from basswood with a quilt maple top, sculpted shredder’s cut heel and scalloped lower back bout for seamless access to the upper registers. The bolt-on caramelized maple neck features graphite reinforcement for rock-solid stability, a satin natural finish on the back of the neck for sublime playability, and a conveniently located heel-mount truss rod adjustment wheel for neck relief tweaks on the fly. Designed for speed, the 12”-16” compound radius ebony fingerboard features comfortable rolled edges, 24 stainless steel jumbo frets and Luminlay® side-dots for enhanced visibility in low-light conditions.
This axe features an HSS pickup configuration consisting of a direct mount Seymour Duncan® Full Shred™ TB-10 bridge pickup and direct mount Seymour Duncan® Custom Flat Strat® SSL-6 single-coil middle pickup and Seymour Duncan Custom Flat Strat SSL-6 RWRP single-coil neck pickup ith plenty of focused humbucker grit and springy vintage snap.
Other premium modern features include a five-way blade pickup switch, speed knobs for the volume and no-load tone controls, Wilkinson® recessed tremolo bridge with locking saddles, Charvel-branded die-cast locking tuners and more.
Blending sophisticated style with assertive tone, the Pro-Mod Plus Dinky® DK24 2PT HSS E QM delivers premium performance and modern features.
| Product Name | Charvel Pro-Mod Plus Dinky DK24 HSS 2PT EB QM Electric Guitar - Blue Curaçao |
|---|---|
| Brand | Charvel |
| Condition | New |
| MPN | 2972813546 |
| UPC | 885978982707 |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- Charvel Pro-Mod Plus Dinky DK24 HSS 2PT EB QM Electric Guitar - Ebony Fingerboard, Blue Curaçao
- Deluxe Gig Bag
- 25.5" scale length
- Basswood Dinky® body with quilt maple top
- Scalloped lower back bout
- Bolt-on maple neck with graphite reinforcement
- Sculpted shredder's cut heel
- 12"-16" compound radius ebony fingerboard with 24 jumbo stainless steel frets
- Heel-mount truss rod adjustment wheel
- Direct mount Seymour Duncan® Full Shred™ TB-10 humbucking bridge and Seymour Duncan Custom Flat Strat® SSL-6 middle and neck single-coil pickups
- Five-way blade switch, volume control and no-load tone control
- Wilkinson® WVS130-2p tremolo bridge with locking saddles
- Charvel-branded die-cast locking tuners
- Included deluxe gig bag
General |
|
|---|---|
| Series | Pro-Mod Plus |
| Orientation | Right-Hand |
| Color | Blue Curaçao |
| Country Of Origin | ID |
Neck |
|
| Headstock | Licensed Fender® Stratocaster® |
| Neck Material | Caramelized Maple |
| Neck Finish | Natural Satin |
| Neck Shape | Speed Neck with Rolled Fingerboard Edges |
| Neck Construction | Bolt-On with Graphite Reinforcement |
| Fingerboard Radius | 12"-16" Compound Radius (304.8 mm to 406.4 mm) |
| Fingerboard Material | Ebony |
| Position Inlays | 4mm Pearloid Dot |
| Side Dots | Luminlay® |
| Number of Frets | 24 |
| Truss Rod | Dual-Action with Wheel |
| Truss Rod Nut | Heel-Mount Truss Rod Adjustment Wheel |
| String Nut | Graph Tech TUSQ XL |
| Nut Width | 1.6875" (42.86 mm) |
| Nut Material | Graph Tech TUSQ XL |
| Fret Size | Jumbo Stainless Steel |
| Scale Length | 25.5" (648 mm) |
Body |
|
| Body | Basswood |
| Body Finish | Gloss |
| Body Shape | Dinky® |
| Body Top | Quilt Maple |
| Body Style | Solid Body |
| Body Material | Basswood |
Hardware |
|
| Bridge | Wilkinson® WVS130-2P Tremolo |
| Pickguard | None |
| Pickup Covers | Black/Cream |
| Control Knobs | Speed Knob |
| Switch Tip | Black |
| Hardware Finish | Chrome |
| Tuning Machines | Charvel®-Branded Die-Cast Locking |
| String Trees | Fender® Standard String Guide |
| Strings | Nickel Plated Steel (.009-.042 Gauges) |
| Tremolo Arm | Wilkinson® |
| Neck Plate | None - 4-Bolt Sculpted Heel |
| Strap Buttons | Standard |
Electronics |
|
| Bridge Pickup | Seymour Duncan® Full Shred™ TB-10 |
| Middle Pickup | Seymour Duncan® Custom Flat Strat® SSL-6 Single-Coil |
| Neck Pickup | Seymour Duncan® Custom Flat Strat® SSL-6 RWRP Single-Coil |
| Pickup Configuration | HSS |
| Controls | Volume (500K EVH® Bourns® Low Friction Pot), No-Load Tone |
| Switching | 5-Position Blade: Position 1. Full Bridge Pickup, Position 2. Bridge Inner Coil and Middle Pickup, Position 3. Bridge Outer Coil and Neck Pickup, Position 4. Middle and Neck Pickup, Position 5. Full Neck Pickup |
