*Please note -- This pre-owned item may show signs of use. Please refer to the photos for details of the product.
With the Drawmer MC2.1 Monitor Controller incorporated into your system you combine the clarity, fidelity and transparency of the highest quality monitoring circuit with the complexity of a host of mix checking features. It is versatile and intuitive, but above everything else, where the Drawmer MC2.1 excels is in it's accuracy and ability to faithfully reproduce what has been recorded.The MC2.1 incorporates four inputs with three stereo balanced speaker outputs, plus a dedicated mono speaker/sub-woofer output each with individual left/right trims under the unit to provide complete control over level matching. The active circuit has been designed to faithfully produce the audio signal whilst removing many of the problems that a passive circuit will bring. In addition, it has a host of mix checking features not often found on other controllers, such as individual left/right cut, as well as two seperate headphone amplifiers and a talkback facility, making the MC2.1 a true engineers tool.Whether you're mastering a cd/dvd, recording, checking a mix for balance and EQ, doing A/B comparisons, plus a mutlitude of other tasks, you'll have spent weeks designing the perfect studio environment and a fortune on active speakers, dynamics processors, various microphone and preamplifier combinations as well as a whole room full other gear, one thing is for sure - a monitor controller is central to every recording setup and probably the most important element of the entire signal chain - providing the reference' listening signal that enables the user to achieve the optimal mic placements, the perfect balance and EQ etc. There is one thing that should always be absolutely guaranteed - that you can rely on the accuracy of your monitor controller.
| Product Name | Drawmer MC2.1 Monitor Controller |
|---|---|
| Brand | Drawmer |
| Condition | Pre-Owned |
| MPN | MC2.1 |
| UPC | 888365196169 |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- Drawmer MC2.1 Monitor Controller
- Rackears
- Drawmer MC2.1 Monitor Controller
- Rackears
General |
|
|---|---|
| Frequency Response | 20 Hz to 20 kHz (±0.2 dB) |
| Phase Response | 20 Hz to 20 kHz (±2°) |
| Maximum Level (Input) | 21 dBu |
| Maximum Level (Output) | 27 dBu |
| Dynamic Range | 118 dB (at Unity Gain) |
| Crosstalk | Left/Right at 1 kHz: >85 dB Adjacent Input: >95 dB |
| THD + N | 0.0014% (Unity Gain, 0 dBu Input) |
Inputs/Outputs |
|
| Audio I/O | 2x Combo XLR-1/4" 3-Pin Line Input (1 Stereo Pair) 2x XLR 3-Pin Line Input (1 Stereo Pair) 1x 2RCA Coaxial Line Input (Unbalanced) 1x 1/8" / 3.5 mm TRS Aux Input 6x XLR 3-Pin Monitor/Speaker Output (3 Stereo Pairs) 1x XLR 3-Pin Speaker Output (Mono/Sub Output) 2x 1/4" TRS Headphone Output 1x 1/4" TS Output (Talkback Output) |
Power |
|
| Power Source | AC Adapter with Power Brick (Included) |
| Power Consumption | 20 VA |
| AC Input Power | 115 / 230 VAC, 50/60 Hz, at 160 to 315 mA (User Selectable) |
Physical |
|
| Color | Black |
| Material of Construction | Steel, Aluminum |
| Dimensions | 10.7 x 8.5 x 3.2" / 27.2 x 21.5 x 8.1 cm |
| Weight | 5.5 lb / 2.5 kg |
Drawmer MC2.1 Monitor Controller
*Please note -- This pre-owned item may show signs of use. Please refer to the photos for details of the product.
With the Drawmer MC2.1 Monitor Controller incorporated into your system you combine the clarity, fidelity and transparency of the highest quality monitoring circuit with the complexity of a host of mix checking features. It is versatile and intuitive, but above everything else, where the Drawmer MC2.1 excels is in it's accuracy and ability to faithfully reproduce what has been recorded.The MC2.1 incorporates four inputs with three stereo balanced speaker outputs, plus a dedicated mono speaker/sub-woofer output each with individual left/right trims under the unit to provide complete control over level matching. The active circuit has been designed to faithfully produce the audio signal whilst removing many of the problems that a passive circuit will bring. In addition, it has a host of mix checking features not often found on other controllers, such as individual left/right cut, as well as two seperate headphone amplifiers and a talkback facility, making the MC2.1 a true engineers tool.Whether you're mastering a cd/dvd, recording, checking a mix for balance and EQ, doing A/B comparisons, plus a mutlitude of other tasks, you'll have spent weeks designing the perfect studio environment and a fortune on active speakers, dynamics processors, various microphone and preamplifier combinations as well as a whole room full other gear, one thing is for sure - a monitor controller is central to every recording setup and probably the most important element of the entire signal chain - providing the reference' listening signal that enables the user to achieve the optimal mic placements, the perfect balance and EQ etc. There is one thing that should always be absolutely guaranteed - that you can rely on the accuracy of your monitor controller.
| Product Name | Drawmer MC2.1 Monitor Controller |
|---|---|
| Brand | Drawmer |
| Condition | Pre-Owned |
| MPN | MC2.1 |
| UPC | 888365196169 |
What's in the Box?
- Drawmer MC2.1 Monitor Controller
- Rackears
- Drawmer MC2.1 Monitor Controller
- Rackears
General |
|
|---|---|
| Frequency Response | 20 Hz to 20 kHz (±0.2 dB) |
| Phase Response | 20 Hz to 20 kHz (±2°) |
| Maximum Level (Input) | 21 dBu |
| Maximum Level (Output) | 27 dBu |
| Dynamic Range | 118 dB (at Unity Gain) |
| Crosstalk | Left/Right at 1 kHz: >85 dB Adjacent Input: >95 dB |
| THD + N | 0.0014% (Unity Gain, 0 dBu Input) |
Inputs/Outputs |
|
| Audio I/O | 2x Combo XLR-1/4" 3-Pin Line Input (1 Stereo Pair) 2x XLR 3-Pin Line Input (1 Stereo Pair) 1x 2RCA Coaxial Line Input (Unbalanced) 1x 1/8" / 3.5 mm TRS Aux Input 6x XLR 3-Pin Monitor/Speaker Output (3 Stereo Pairs) 1x XLR 3-Pin Speaker Output (Mono/Sub Output) 2x 1/4" TRS Headphone Output 1x 1/4" TS Output (Talkback Output) |
Power |
|
| Power Source | AC Adapter with Power Brick (Included) |
| Power Consumption | 20 VA |
| AC Input Power | 115 / 230 VAC, 50/60 Hz, at 160 to 315 mA (User Selectable) |
Physical |
|
| Color | Black |
| Material of Construction | Steel, Aluminum |
| Dimensions | 10.7 x 8.5 x 3.2" / 27.2 x 21.5 x 8.1 cm |
| Weight | 5.5 lb / 2.5 kg |
