*Please note -- This pre-owned item may show signs of use. Please refer to the photos for details of the product.
Improving on their first generation model, the smaller of their first two monitors, Pulsar is an ideal choice for nearfield and midfield monitoring applications in any setup, or as primary monitors in small- to medium-sized rooms. Like all our monitors, Pulsar features custom SEAS drivers with custom designed cutting edge diaphragm materials designed in collaboration with Composite Sound, featuring their Metamodal TX™ mid-range and tweeter diaphragms, acoustically inert, sealed Valchromat® cabinets, Hypex Ncore® amps, and AKM AK5572EN & AK4493EQ conversion, and dedicated 5th generation SHARC® DSP per speaker, deploying higher computing headroom and our improved proprietary calibration technology. And, like all their monitors, it offers an ultra-wide sweet spot, linear phase and magnitude response, vanishingly low distortion, and superb transient response for effortless clarity and highly detailed insight into your mixes. Allowing you to make better decisions, faster, every time.
| Product Name | Ex Machina Soundworks Pulsar MKII Studio Monitor - Single |
|---|---|
| Brand | Ex Machina Soundworks |
| Condition | Pre-Owned |
| MPN | EXPULSARMKII |
| Shipping Option | Free Shipping to the Continental U.S. |
What's in the Box?
- Ex Machina Soundworks Pulsar MKII Studio Monitor - Single
- Linear Frequency Response: +/- 1db 35hz – 32khz
- Low Frequency Cutoff: -6db at 28hz
- Linear Phase Response: +/- 15° 20hz – 30khz
- Maximum Continuous SPL @ 1m: 110db, 104db @50hz
- THD+N (94db @ 1m): < .5% Power Average 100hz – 30khz
- Constant Directivity Index: 90° conical (+/- 3db to 18khz)
Frequency Response & Performance |
|
|---|---|
| Linear Frequency Response | +/- 1db 35hz – 30khz (measured at 30cm cal position) |
| Low Frequency Cutoff | -6db at 28hz |
| Linear Phase Response | +/- 15° 20hz – 30khz |
| Maximum Continuous SPL @ 1m | 110db, 104db @50hz |
| THD+N (94db @ cal position) | < .5% Power Average 100hz – 30khz |
| Coverage Angle | 90° conical |
Driver Complement |
|
| Midrange / Tweeter | 176mm (7”) midrange, 25mm (1”) tweeter Custom SEAS/Ex Machina/Composite Sound Metamodal TX™ mid/high coaxial |
| Subwoofer | 221mm (9”) Custom Aluminum SEAS Extreme Series Architecture Subwoofer |
Crossovers |
|
| Sub/Mid Crossover | 200hz Sub/Mid, digital 8th order, phase corrected |
| Mid/Tweet Crossover | 2khz Mid/Tweet, digital 8th order, phase corrected |
Amplifier Complement |
|
| Subwoofer | Hypex NC252MP – 250W RMS |
| Midrange | Hypex NC252MP – 100W RMS, voltage limited |
| Tweeter | Hypex NC100HF – 50W RMS, voltage limited |
DSP/Conversion |
|
| A/D Chipsets | AKM AK5572EN |
| D/A Chipsets | AKM AK4493EQ |
| DSP | 5th Gen SHARC+ AD21565 |
Input Sensitivity |
|
| Input Sensitivity | 2vrms to full scale |
Mass & Dimensions |
|
| Dimensions (H x W x D) | 483mm H x 289mm W x 345mm D (19″ x 11.3″ x 13.6″) |
| Weight | 23kg (51lbs) |
*Please note -- This pre-owned item may show signs of use. Please refer to the photos for details of the product.
Improving on their first generation model, the smaller of their first two monitors, Pulsar is an ideal choice for nearfield and midfield monitoring applications in any setup, or as primary monitors in small- to medium-sized rooms. Like all our monitors, Pulsar features custom SEAS drivers with custom designed cutting edge diaphragm materials designed in collaboration with Composite Sound, featuring their Metamodal TX™ mid-range and tweeter diaphragms, acoustically inert, sealed Valchromat® cabinets, Hypex Ncore® amps, and AKM AK5572EN & AK4493EQ conversion, and dedicated 5th generation SHARC® DSP per speaker, deploying higher computing headroom and our improved proprietary calibration technology. And, like all their monitors, it offers an ultra-wide sweet spot, linear phase and magnitude response, vanishingly low distortion, and superb transient response for effortless clarity and highly detailed insight into your mixes. Allowing you to make better decisions, faster, every time.
| Product Name | Ex Machina Soundworks Pulsar MKII Studio Monitor - Single |
|---|---|
| Brand | Ex Machina Soundworks |
| Condition | Pre-Owned |
| MPN | EXPULSARMKII |
What's in the Box?
Ex Machina Soundworks Pulsar MKII Studio Monitor - Single- Linear Frequency Response: +/- 1db 35hz – 32khz
- Low Frequency Cutoff: -6db at 28hz
- Linear Phase Response: +/- 15° 20hz – 30khz
- Maximum Continuous SPL @ 1m: 110db, 104db @50hz
- THD+N (94db @ 1m): < .5% Power Average 100hz – 30khz
- Constant Directivity Index: 90° conical (+/- 3db to 18khz)
Frequency Response & Performance |
|
|---|---|
| Linear Frequency Response | +/- 1db 35hz – 30khz (measured at 30cm cal position) |
| Low Frequency Cutoff | -6db at 28hz |
| Linear Phase Response | +/- 15° 20hz – 30khz |
| Maximum Continuous SPL @ 1m | 110db, 104db @50hz |
| THD+N (94db @ cal position) | < .5% Power Average 100hz – 30khz |
| Coverage Angle | 90° conical |
Driver Complement |
|
| Midrange / Tweeter | 176mm (7”) midrange, 25mm (1”) tweeter Custom SEAS/Ex Machina/Composite Sound Metamodal TX™ mid/high coaxial |
| Subwoofer | 221mm (9”) Custom Aluminum SEAS Extreme Series Architecture Subwoofer |
Crossovers |
|
| Sub/Mid Crossover | 200hz Sub/Mid, digital 8th order, phase corrected |
| Mid/Tweet Crossover | 2khz Mid/Tweet, digital 8th order, phase corrected |
Amplifier Complement |
|
| Subwoofer | Hypex NC252MP – 250W RMS |
| Midrange | Hypex NC252MP – 100W RMS, voltage limited |
| Tweeter | Hypex NC100HF – 50W RMS, voltage limited |
DSP/Conversion |
|
| A/D Chipsets | AKM AK5572EN |
| D/A Chipsets | AKM AK4493EQ |
| DSP | 5th Gen SHARC+ AD21565 |
Input Sensitivity |
|
| Input Sensitivity | 2vrms to full scale |
Mass & Dimensions |
|
| Dimensions (H x W x D) | 483mm H x 289mm W x 345mm D (19″ x 11.3″ x 13.6″) |
| Weight | 23kg (51lbs) |
