Fryette Amplification introduces ZMACS, the world’s first and only selectable and programmable Impedance Matching Amp & Cab Selector!
- Allows switching between any of 4 amplifiers, 4 cabs and 2 attenuators.
- Allows selection of 2 cabs simultaneously.
- Safely handles 100 watts of continuous amplifier power.
- Built-in high-fidelity audio grade impedance matching transformer.
- Selectable Amp impedance - 2/4, 8 and 16 Ohms (programmable).
- Selectable Cabinet impedance - 2/4, 8 and 16 Ohms (programmable).
- Safety internal load for each unused amplifier output.
- Switched and unswitched attenuator loops.
- Front and rear panel instrument inputs.
- Passive and active (buffered) instrument inputs.
- Link Out for ganging multiple switching units.
- Fully MIDI programmable and simple to operate.
- Last used preset memory.
- Long cable load transfer.
- Silent switching in all modes with no dropouts, pops or clicks.
- Transformer isolated amplifier input sends eliminate annoying ground loop issues.
- Remote switching control port controls Power Station PS-100 channel and loop select functions.
- QuickSwitch mode allows simple preset selection when MIDI is not required.
- 100% analog signal path
| Product Name | Fryette ZMACS 4X4 Impedance Matching Amp/Cab Selector |
|---|---|
| Brand | Fryette |
| Condition | New |
| MPN | ZMACS |
| UPC | 851473006767 |
| Shipping Option | Free Shipping to the Continental U.S. |
- Allows switching between any of 4 amplifiers, 4 cabs and 2 attenuators.
- Allows selection of 2 cabs simultaneously.
- Safely handles 100 watts of continuous amplifier power.
- Built-in high-fidelity audio grade impedance matching transformer.
- Selectable Amp impedance - 2/4, 8 and 16 Ohms (programmable).
- Selectable Cabinet impedance - 2/4, 8 and 16 Ohms (programmable).
- Safety internal load for each unused amplifier output.
- Switched and unswitched attenuator loops.
- Front and rear panel instrument inputs.
- Passive and active (buffered) instrument inputs.
- Link Out for ganging multiple switching units.
- Fully MIDI programmable and simple to operate.
- Last used preset memory.
- Long cable load transfer.
- Silent switching in all modes with no dropouts, pops or clicks.
- Transformer isolated amplifier input sends eliminate annoying ground loop issues.
- Remote switching control port controls Power Station PS-100 channel and loop select functions.
- QuickSwitch mode allows simple preset selection when MIDI is not required.
- 100% analog signal path
| Model | ZMACS |
| Model Number | 4X4 |
| Power Requirement | Regulated 12 Volts DC @ 300mA |
| Instrument Input Impedance | 1 Megohm |
| Active Output Impedance | 100 ohms |
| Height | 1.75" (44 mm) |
| Width | 17.00" (432 mm) 19.00" (483 mm) with rack ears |
| Depth | 9.06" (230 mm) |
| Weight | 12 lbs (5.5 kg) |
Fryette ZMACS 4X4 Impedance Matching Amp/Cab Selector
Details
Fryette Amplification introduces ZMACS, the world’s first and only selectable and programmable Impedance Matching Amp & Cab Selector!
- Allows switching between any of 4 amplifiers, 4 cabs and 2 attenuators.
- Allows selection of 2 cabs simultaneously.
- Safely handles 100 watts of continuous amplifier power.
- Built-in high-fidelity audio grade impedance matching transformer.
- Selectable Amp impedance - 2/4, 8 and 16 Ohms (programmable).
- Selectable Cabinet impedance - 2/4, 8 and 16 Ohms (programmable).
- Safety internal load for each unused amplifier output.
- Switched and unswitched attenuator loops.
- Front and rear panel instrument inputs.
- Passive and active (buffered) instrument inputs.
- Link Out for ganging multiple switching units.
- Fully MIDI programmable and simple to operate.
- Last used preset memory.
- Long cable load transfer.
- Silent switching in all modes with no dropouts, pops or clicks.
- Transformer isolated amplifier input sends eliminate annoying ground loop issues.
- Remote switching control port controls Power Station PS-100 channel and loop select functions.
- QuickSwitch mode allows simple preset selection when MIDI is not required.
- 100% analog signal path
| Product Name | Fryette ZMACS 4X4 Impedance Matching Amp/Cab Selector |
|---|---|
| Brand | Fryette |
| Condition | New |
| MPN | ZMACS |
| UPC | 851473006767 |
Features
- Allows switching between any of 4 amplifiers, 4 cabs and 2 attenuators.
- Allows selection of 2 cabs simultaneously.
- Safely handles 100 watts of continuous amplifier power.
- Built-in high-fidelity audio grade impedance matching transformer.
- Selectable Amp impedance - 2/4, 8 and 16 Ohms (programmable).
- Selectable Cabinet impedance - 2/4, 8 and 16 Ohms (programmable).
- Safety internal load for each unused amplifier output.
- Switched and unswitched attenuator loops.
- Front and rear panel instrument inputs.
- Passive and active (buffered) instrument inputs.
- Link Out for ganging multiple switching units.
- Fully MIDI programmable and simple to operate.
- Last used preset memory.
- Long cable load transfer.
- Silent switching in all modes with no dropouts, pops or clicks.
- Transformer isolated amplifier input sends eliminate annoying ground loop issues.
- Remote switching control port controls Power Station PS-100 channel and loop select functions.
- QuickSwitch mode allows simple preset selection when MIDI is not required.
- 100% analog signal path
Tech Specs
| Model | ZMACS |
| Model Number | 4X4 |
| Power Requirement | Regulated 12 Volts DC @ 300mA |
| Instrument Input Impedance | 1 Megohm |
| Active Output Impedance | 100 ohms |
| Height | 1.75" (44 mm) |
| Width | 17.00" (432 mm) 19.00" (483 mm) with rack ears |
| Depth | 9.06" (230 mm) |
| Weight | 12 lbs (5.5 kg) |
