JZ Microphone Vintage 12 Microphone

JZ Microphone Vintage 12 Microphone

Condition:

On order with the manufacturer!

AKG C12 is considered one of the best tube condenser microphones ever, it has been a inspiration for many other manufacturers and its CK12 capsule still is one the best microphone capsule built.
View full details
  • Details
  • Reviews
AKG C12 is considered one of the best tube condenser microphones ever, it has been a inspiration for many other manufacturers and its CK12 capsule still is one the best microphone capsule built. JZ Microphones now offers our version of C12 – the new Vintage 12 follows the success of V47 & V67. JZ Microphones have adopted best qualities of C12 and added their signature by using Golden Drop Technology for GDC12 capsule and replacing transistors instrad of tubes. Vintage 12 still has the same design of Vintage series, the inner shock-mounting system, adjustable swivel moun and two layer mesh instead of three layer mesh.

Vintage 12
Transducer type electrostatic
Operating principal pressure gradient
Diaphragms active diameter 25 mm
Frequency range 20 Hz to 20 kHz
Polar pattern cardioid
Output impedance 50 ohms
Rated load impedance 1000 ohms
Suggested load impedance > 500 ohms
Sensitivity at 1000 Hz into 1000 ohms load 22 mV/Pa
S/N Ratio CCIR 468-3 weighted 76 dB
S/N Ratio DIN/IEC 651 A-weighted 87 db-A
Equivalent noise level DIN/IEC A-weighted 6 dB-A
Maximum SPL for 0.5% THD at 1000 ohm load 134 dB
Dynamic range of the microphone preamplifier 128 db
Phantom powering voltage on pins 2 & 3 of XLR +48 V (+/-4 V)
Current consumption < 2 mA
Output connector 3-pin XLR male, gold plated contacts
Signal polarity
positive toward pressure on a diaphragm produces positive polarity voltage on XLR pin #2 relatively to pin #3
More Information
Product Name JZ Microphone Vintage 12 Microphone
Brand JZ Microphones
Shipping Option Free Shipping to the Continental U.S.
