Moog Minitaur Analog Bass Monosynth Module Black

Moog Minitaur Analog Bass Monosynth Module Black

On order with the manufacturer!

Moog Minitaur Analog Bass Monosynth Module. Minitaur is a powerful, compact Analog Bass Synthesizer that features a classic one knob per function design.
View full details
  • Details
  • Features
  • Tech Specs
  • Reviews

Moog Minitaur Analog Bass Monosynth Module

Minitaur is the ultimate bass machine--an inconspicuously compact analog synthesizer that delivers a massive low end punch. Minitaur’s no-nonsense design and knob-per-function front panel put the full spectrum of earth-shaking sub-bass frequencies right at your fingertips.

This secret weapon of artists and producers around the globe has been upgraded with new firmware, greatly expanding the instrument’s sonic capabilities: create evolving organic bass that moves by isolating modulations to oscillator 2 only, or engage hard sync to turn Minitaur into a hyper-focused bass laser with pinpoint accuracy. Five new modulation wave shapes unlock access to syncopated sweeps and analog percussion sounds, while Minitaur’s assignable CV/GATE inputs allow a world of inter-connective possibilities to unfold “outside of the box”.

Reach beyond the front panel and dig even deeper into the Minitaur’s analog circuits with the free Minitaur Editor/Librarian software, creating a seamless integration with your computer-based workflow on Mac or Windows. Every feature can be manipulated, automated and recalled instantly, injecting the full power of deep analog bass into your DAW.

The Minitaur now ships with v2.2 firmware! The new Minitaur v2.2 update expands this powerful analog bass synthesizer with a host of new performance elements and user requested features, including front-panel access to new LFO wave-shapes, oscillator hard-sync and much more--and Minitaur's new Librarian/Editor Software makes DAW integration seamless between your synthesizer and Mac or Windows machine.

More Information
Product Name Moog Minitaur Analog Bass Monosynth Module Black
Brand Moog
Condition New
MPN MOOGBASSSYNTHESIZER
UPC 094922371089
Shipping Option Free Shipping to the Continental U.S.
  • SAVE AND RECALL UP TO 128 ONBOARD PRESETS - Select and save directly from your Minitaur’s front panel, via MIDI controller or with the free Minitaur Editor / Librarian software.
  • FREE EDITOR/LIBRARIAN SOFTWARE - Seamless DAW integration now with full Windows support!
  • 5 NEW MODULATION SOURCES (Tri, Sqr, Saw, Ramp, S&H and Filter EG)
  • HARD SYNC - Access a completely new sonic palette with your Minitaur
  • MODULATE OSCILLATOR 2 ONLY - Pair with Hard Sync for syncopated metallic sweeps and surges
  • ASSIGNABLE CV/GATE INPUTS - Control any feature on or under the hood of your Minitaur via control voltage.
  • CV TO MIDI CONVERSION - Bring control voltage into your DAW for analog control over digital circuits
  • SOUND ENGINE: Analog
  • PRESETS: 128 Presets
  • POLYPHONY: Monophonic (can be poly-chained)
  • EXTERNAL CONTROLLER RESPONSE: Keyboard, Pitch Bend, Mod Wheel, After Pressure and Velocity
  • SOUND SOURCES: 2 Waveshape Oscillators with Square and Saw waveshapes
  • VCO 2 FREQ: +/-12 Semitones
  • HARD SYNC: On/Off
  • OSCILLATOR CALIBRATION RANGE: 22Hz-6.8KHz. Note range at 8’ = 18 - 116
  • GLIDE: Select LCR, LCT, EXP - Legato On/Off
  • FILTER: 20Hz-20KHz Moog Ladder Filter
  • MODULATION SOURCES: LFO (Triange, Square, Saw, Ramp, Sample & Hold), Filter Envelope
  • MODULATION DESTINATIONS: Oscillator Pitch, Oscillator 2 Pitch only, Filter Cutoff
  • LFO PANEL FEATURES: Rate control, VCO LFO Amount and VCF LFO Amount
  • ENVELOPES: 2x ADSR Envelopes with Legato On, Legato Off and EG Reset
  • EXTERNAL AUDIO INPUT: ¼” TS
  • AUDIO OUTPUT: ¼” TS, â…›” TRS Headphone with volume control
  • MIDI I/O: DIN In, and MIDI I/O over USB
  • ASSIGNABLE CV/GATE INPUTS: Filter CV (Fixed Dest.), Pitch CV (Default), Volume CV (Default), KB Gate (Default)
  • CV TO MIDI CONVERSION: Yes
  • INCLUDED POWER SUPPLY: 100-250VAC, 50-60Hz, +12VDC
  • WEIGHT: 2.5lbs (1.2kg)
  • DIMENSIONS: 3.1”H x 8.75”W x 5.1”D

Moog Minitaur Analog Bass Monosynth Module Black

Details

Moog Minitaur Analog Bass Monosynth Module

Minitaur is the ultimate bass machine--an inconspicuously compact analog synthesizer that delivers a massive low end punch. Minitaur’s no-nonsense design and knob-per-function front panel put the full spectrum of earth-shaking sub-bass frequencies right at your fingertips.

This secret weapon of artists and producers around the globe has been upgraded with new firmware, greatly expanding the instrument’s sonic capabilities: create evolving organic bass that moves by isolating modulations to oscillator 2 only, or engage hard sync to turn Minitaur into a hyper-focused bass laser with pinpoint accuracy. Five new modulation wave shapes unlock access to syncopated sweeps and analog percussion sounds, while Minitaur’s assignable CV/GATE inputs allow a world of inter-connective possibilities to unfold “outside of the box”.

Reach beyond the front panel and dig even deeper into the Minitaur’s analog circuits with the free Minitaur Editor/Librarian software, creating a seamless integration with your computer-based workflow on Mac or Windows. Every feature can be manipulated, automated and recalled instantly, injecting the full power of deep analog bass into your DAW.

The Minitaur now ships with v2.2 firmware! The new Minitaur v2.2 update expands this powerful analog bass synthesizer with a host of new performance elements and user requested features, including front-panel access to new LFO wave-shapes, oscillator hard-sync and much more--and Minitaur's new Librarian/Editor Software makes DAW integration seamless between your synthesizer and Mac or Windows machine.

More Information
Product Name Moog Minitaur Analog Bass Monosynth Module Black
Brand Moog
Condition New
MPN MOOGBASSSYNTHESIZER
UPC 094922371089
Shipping Option Free Shipping to the Continental U.S.
Features
  • SAVE AND RECALL UP TO 128 ONBOARD PRESETS - Select and save directly from your Minitaur’s front panel, via MIDI controller or with the free Minitaur Editor / Librarian software.
  • FREE EDITOR/LIBRARIAN SOFTWARE - Seamless DAW integration now with full Windows support!
  • 5 NEW MODULATION SOURCES (Tri, Sqr, Saw, Ramp, S&H and Filter EG)
  • HARD SYNC - Access a completely new sonic palette with your Minitaur
  • MODULATE OSCILLATOR 2 ONLY - Pair with Hard Sync for syncopated metallic sweeps and surges
  • ASSIGNABLE CV/GATE INPUTS - Control any feature on or under the hood of your Minitaur via control voltage.
  • CV TO MIDI CONVERSION - Bring control voltage into your DAW for analog control over digital circuits
Tech Specs
  • SOUND ENGINE: Analog
  • PRESETS: 128 Presets
  • POLYPHONY: Monophonic (can be poly-chained)
  • EXTERNAL CONTROLLER RESPONSE: Keyboard, Pitch Bend, Mod Wheel, After Pressure and Velocity
  • SOUND SOURCES: 2 Waveshape Oscillators with Square and Saw waveshapes
  • VCO 2 FREQ: +/-12 Semitones
  • HARD SYNC: On/Off
  • OSCILLATOR CALIBRATION RANGE: 22Hz-6.8KHz. Note range at 8’ = 18 - 116
  • GLIDE: Select LCR, LCT, EXP - Legato On/Off
  • FILTER: 20Hz-20KHz Moog Ladder Filter
  • MODULATION SOURCES: LFO (Triange, Square, Saw, Ramp, Sample & Hold), Filter Envelope
  • MODULATION DESTINATIONS: Oscillator Pitch, Oscillator 2 Pitch only, Filter Cutoff
  • LFO PANEL FEATURES: Rate control, VCO LFO Amount and VCF LFO Amount
  • ENVELOPES: 2x ADSR Envelopes with Legato On, Legato Off and EG Reset
  • EXTERNAL AUDIO INPUT: ¼” TS
  • AUDIO OUTPUT: ¼” TS, â…›” TRS Headphone with volume control
  • MIDI I/O: DIN In, and MIDI I/O over USB
  • ASSIGNABLE CV/GATE INPUTS: Filter CV (Fixed Dest.), Pitch CV (Default), Volume CV (Default), KB Gate (Default)
  • CV TO MIDI CONVERSION: Yes
  • INCLUDED POWER SUPPLY: 100-250VAC, 50-60Hz, +12VDC
  • WEIGHT: 2.5lbs (1.2kg)
  • DIMENSIONS: 3.1”H x 8.75”W x 5.1”D
