TONEFUEL 4 & TONEFUEL 8 — CLEAN, ISOLATED POWER FOR EVERY PEDAL ON YOUR BOARD
A great pedalboard deserves better than a noisy daisy chain. Shared grounds and unregulated supplies bring hum, buzz and ground-loop noise straight into your signal path. TONEFUEL 4 and TONEFUEL 8 stop the problem at its source. They are compact, multi-output power supplies that give each pedal its own clean, regulated 9 V DC feed — so the only thing you hear is your tone.
TONEFUEL 4 delivers 4 independent outputs. Two are 100 mA outputs for standard analog effects, and two higher-current outputs (400 mA and 600 mA) handle the demanding pedals. It is ideal for compact boards, or as a satellite supply for a couple of power-hungry units. TONEFUEL 8 steps up to 8 independent outputs — 6 × 100 mA and 2 × 300 mA — giving larger pedalboards the headroom for a full mix of analog and digital effects.
Both units run from a single USB-C connection (5 V, 3 A). A status LED on every channel shows at a glance which outputs are live. The rugged, low-profile enclosure mounts easily under or alongside your pedalboard. Pure, quiet power.
| Product Name | TC Electronic TONEFUEL 4 - Pedalboard Power Supply |
|---|---|
| Brand | TC Electronic |
| Condition | New |
| MPN | 0709-AMH86-US1 |
| Shipping Option | Free Shipping on orders over $94.72 |
What's in the Box?
- TC Electronic TONEFUEL 4 - Pedalboard Power Supply
- Four independently isolated, regulated 9 V DC outputs for powering effects pedals
- Output capacities: 2 × 100 mA, 1 × 400 mA, and 1 × 600 mA
- 1 A maximum combined output
- USB-C power input rated at 5 V / 3 A
- Independent overcurrent and short-circuit protection on every channel
- Four top-panel status LEDs, one per output channel
- Includes four DC output cables and one 5 V / 3 A USB-C power adapter
TONEFUEL 4 & TONEFUEL 8 — CLEAN, ISOLATED POWER FOR EVERY PEDAL ON YOUR BOARD
A great pedalboard deserves better than a noisy daisy chain. Shared grounds and unregulated supplies bring hum, buzz and ground-loop noise straight into your signal path. TONEFUEL 4 and TONEFUEL 8 stop the problem at its source. They are compact, multi-output power supplies that give each pedal its own clean, regulated 9 V DC feed — so the only thing you hear is your tone.
TONEFUEL 4 delivers 4 independent outputs. Two are 100 mA outputs for standard analog effects, and two higher-current outputs (400 mA and 600 mA) handle the demanding pedals. It is ideal for compact boards, or as a satellite supply for a couple of power-hungry units. TONEFUEL 8 steps up to 8 independent outputs — 6 × 100 mA and 2 × 300 mA — giving larger pedalboards the headroom for a full mix of analog and digital effects.
Both units run from a single USB-C connection (5 V, 3 A). A status LED on every channel shows at a glance which outputs are live. The rugged, low-profile enclosure mounts easily under or alongside your pedalboard. Pure, quiet power.
| Product Name | TC Electronic TONEFUEL 4 - Pedalboard Power Supply |
|---|---|
| Brand | TC Electronic |
| Condition | New |
| MPN | 0709-AMH86-US1 |
What's in the Box?
TC Electronic TONEFUEL 4 - Pedalboard Power Supply- Four independently isolated, regulated 9 V DC outputs for powering effects pedals
- Output capacities: 2 × 100 mA, 1 × 400 mA, and 1 × 600 mA
- 1 A maximum combined output
- USB-C power input rated at 5 V / 3 A
- Independent overcurrent and short-circuit protection on every channel
- Four top-panel status LEDs, one per output channel
- Includes four DC output cables and one 5 V / 3 A USB-C power adapter
